High efficiency precision filter
–C– the main pipe passes through the filter element, which is mostly used after the air compressor, the rear cooler or the freeze dryer, and can filter out a large amount of liquid and solid particles above 3um, reaching the minimum residual oil content of only 5ppm.
–T– Class air line filter element, mostly used for tools, machinery, motors, cylinders and other equipment and A class filter before or after the adsorption dryer, can filter 1um of liquid and solid particles, to achieve a minimum residual oil content of only 5ppm.
–A– grade ultra-efficient oil removal filter core, mostly used for adsorption dryer upstream or frozen dryer upstream filter 0.0lum of liquid and solid particles, to achieve the minimum residual oil content of only 0.00lppm.
–H– grade active carbon micro-oil mist filter element, mostly used to purify food, medicine, respiratory gas, can filter 0.0lμm of oil mist and hydrocarbons, to achieve the minimum residual oil content of only 0.003ppm.
With the progress of science and technology, modern enterprises are thriving, and almost every industry needs compressed air. Oil and gas separation filter adopts special multi-layer structure, oil-bearing air oil absorption layer, condensate layer, separation layer multi-layer interception, the oil is separated out to obtain the required clean air, is an indispensable filter element of air braider.
Products features: high filtration accuracy, minimal residual flow, high compressive strength, etc
The pre-filter is installed in the line to remove solid particles and oil particles for clean air. High efficiency, ultra-high efficiency filters are installed in the branch to remove very small solid particles and oil particles to obtain very clean air to protect important components.
Folding film filter element
Filter membrane core and filter are currently the international popular microporous filtration equipment. It uses compound folding microporous membrane as the filter medium, through the membrane surface microporous screening, to achieve a certain filtering effect, with high filtration accuracy, good filtrate quality, small filter volume, large flow, easy operation and low production cost. Among them, the pure polypropylene plastic shell microporous membrane liquid filter has the characteristics of good corrosion resistance, high temperature resistance, small size, light weight, non-toxicity, non-fouling and non-pollution, which is suitable for low pressure and high precision filtration of highly corrosive media in medicine, food, chemical industry, pesticide and other industries. All kinds of microporous filter elements matched with the high-precision filter membrane core ensure the high efficiency and service life of the membrane core.
The honeycomb wire is wound through the filter element
Wire-wound filter element is a kind of deep filter element with excellent sealing, which is made of textile fiber, according to a specific process, tightly wound on the porous skeleton, forming a honeycomb structure with sparse outside and dense inside. It has very excellent filtration characteristics, and can effectively remove impurities such as suspended matter, rust and particles in the fluid. Beehive type wire bypass filter is a replacement product based on today’s international advanced technology, aiming at the shortcomings of the previous wire wound filter, such as large resistance and short life. Advanced winding technology is adopted, and the service life is about twice as long. Thus, the number of core changes is reduced and the cost of use is reduced.
Post time: May-10-2024
